The TSW212 is a Layer 2 managed Ethernet switch with advanced Layer 3 features such as DHCPv6 client support and static IPv6 routing. With 8 Gigabit Ethernet ports and 2 SFP ports, this industrial switch offers reliable and fast communication over long distances via fiber optics.
It supports key industrial protocols such as EtherNet/IP, PROFINET and MRP, making it perfect for automation and critical network infrastructure. The TSW212 is designed for high reliability and performance – an ideal solution for smart industrial networks.
Regular price
1 148 SEK
Regular price
Sale price
1 148 SEK
Unit price
per
Excl. VAT
Produktnummer: TSW212000000
Couldn't load pickup availability
What's in the box?
What's in the box?
Row that can be hiddensaxasa
Row that can be hiddensaxasa
Tekniska specifikationer
Ethernet
ETH: Multilayer managed 8 x ETH ports, 10/100/1000 Mbps with support for auto MDI/MDIX crossover
Fiber: 2 x SFP ports
IEEE 802.3 standards: 802.3i, 802.3u, 802.3ab, 802.3x, 802.3z
Fiber: 2 x SFP ports
IEEE 802.3 standards: 802.3i, 802.3u, 802.3ab, 802.3x, 802.3z
INDUSTRIAL PROTOCOLS
Profinet: Profinet Class B compatibility (available with option code)
Services
EtherNet/IP: Yes
SNMP V2, V3: Yes
LLDP: Yes
Network management: 802.1p class of service, 802.1x port-based network access control, 802.1Q VLAN
SNMP V2, V3: Yes
LLDP: Yes
Network management: 802.1p class of service, 802.1x port-based network access control, 802.1Q VLAN
Network
MRP: MRP client role, MRP manager role
L2 features: Loop protection, forwarding table, VLAN, STP/RSTP
DHCP: DHCP server, DHCP client, DHCP static leases with support for wildcard MACs
Port Settings: Enable/Disable, Link Speed Control, Port Isolation, EEE (802.3az) Management, Port Mirroring
L3 Features: Static IPv4 Routing, Static IPv6 Routing, DHCPv6 Client, Static IPv6 Address
L2 features: Loop protection, forwarding table, VLAN, STP/RSTP
DHCP: DHCP server, DHCP client, DHCP static leases with support for wildcard MACs
Port Settings: Enable/Disable, Link Speed Control, Port Isolation, EEE (802.3az) Management, Port Mirroring
L3 Features: Static IPv4 Routing, Static IPv6 Routing, DHCPv6 Client, Static IPv6 Address
Security
Authentication: PAM — Shared Key, Radius & TACACS+, IP and Login Attempt Blocking
QoS
QOS: Port priority, DSCP priority, 802.1p priority, TOS
Scheduling method: SP/WFQ/WRR
Bandwidth control: Speed limiting, storm control
Traffic shaper: Port-based shaping
Scheduling method: SP/WFQ/WRR
Bandwidth control: Speed limiting, storm control
Traffic shaper: Port-based shaping
Diagnostics
Tools: Cable fault diagnostics, ping, traceroute, nslookup
API
Teltonika Networks Web API (beta) support: Extend the capabilities of your device with configurable API endpoints to retrieve or modify data. More information can be found here: https://developers.teltonika-networks.com
System properties
RAM: 128MB, DDR3
FLASH memory: 16 MB serial flash memory
FLASH memory: 16 MB serial flash memory
Firmware / Configuration
WEB UI: Update firmware from file, check firmware on server, configuration profiles, configuration backup
FOTA: Firmware update over the air
RMS: Update firmware/configuration for multiple devices at once
Keep settings: Update firmware without losing existing configuration
FOTA: Firmware update over the air
RMS: Update firmware/configuration for multiple devices at once
Keep settings: Update firmware without losing existing configuration
Firmware customization
Operating system: TSWOS (OpenWrt-based Linux OS)
Supported languages: Busybox shell, Lua, C, C++
Development tools: SDK package with build environment included
Supported languages: Busybox shell, Lua, C, C++
Development tools: SDK package with build environment included
Performance specifications
Bandwidth (non-blocking): 20 Gbps
Forwarding speed: 14.88 Mpps
Packet buffer: 512 KB
MAC address table size: 8K entries
Jumbo frame support: 10,000 bytes
Forwarding speed: 14.88 Mpps
Packet buffer: 512 KB
MAC address table size: 8K entries
Jumbo frame support: 10,000 bytes
Current
Connection: 2-pin industrial DC power connector
Input voltage range: 7 – 57 VDC
Power consumption: Sleep: < 2.5 W / Max: 6 W
Input voltage range: 7 – 57 VDC
Power consumption: Sleep: < 2.5 W / Max: 6 W
Physical interfaces
Ethernet: 8 x RJ45 ports, 10/100/1000 Mbps
Fiber: 2 x SFP ports
Status LEDs: 1 x Power LED, 1 x Aux LED, 16 x ETH status LEDs, 2 x SFP status LEDs
Power: 1 x 2-pin industrial DC power connector
Reset: Software reset button
Other: 1 x grounding screw
Fiber: 2 x SFP ports
Status LEDs: 1 x Power LED, 1 x Aux LED, 16 x ETH status LEDs, 2 x SFP status LEDs
Power: 1 x 2-pin industrial DC power connector
Reset: Software reset button
Other: 1 x grounding screw
Physical specifications
Enclosure material: Anodized aluminum housing and panels
Dimensions (W x H x D): 132 x 44.2 x 122.2 mm
Weight: 615g
Mounting options: Integrated DIN rail mount; wall mount and flat surface (accessory kit required)
Dimensions (W x H x D): 132 x 44.2 x 122.2 mm
Weight: 615g
Mounting options: Integrated DIN rail mount; wall mount and flat surface (accessory kit required)
Operating environment
Operating temperature: -40°C to 75°C
Operating humidity: 5% to 95% non-condensing
Ingress Protection Rating: IP30
Operating humidity: 5% to 95% non-condensing
Ingress Protection Rating: IP30
Regulations & Type Approvals
Regulations: CE, UKCA, RCM, ANRT, FCC, IC, CB, WEEE, RoHS, REACH, SDPPI (POSTEL), JATE, Kenya, ICASA, Giteki, NBCT, ICASA, PROFINET, UL Safety
EMC emissions & immunity
Standards: EN 55032:2015 + A11:2020 + A1:2020
EN 55035:2017 + A11:2020
EN IEC 61000-3-2:2019 + A1:2021
EN 61000-3-3:2013 + A1:2019 + A2:2021
ESD: EN 61000-4-2:2009
Radiated Immunity: EN IEC 61000-4-3:2020
EFT: EN 61000-4-4:2012
Surge Immunity (AC mains voltage port): EN 61000-4-5:2014 + A1:2017
CS: EN 61000-4-6:2014
DIP: EN 61000-4-11:2020
EN 55035:2017 + A11:2020
EN IEC 61000-3-2:2019 + A1:2021
EN 61000-3-3:2013 + A1:2019 + A2:2021
ESD: EN 61000-4-2:2009
Radiated Immunity: EN IEC 61000-4-3:2020
EFT: EN 61000-4-4:2012
Surge Immunity (AC mains voltage port): EN 61000-4-5:2014 + A1:2017
CS: EN 61000-4-6:2014
DIP: EN 61000-4-11:2020
Security
Standards: CE: EN IEC 62368-1:2020 + A11:2020
RCM: AS/NZS 62368.1:2022
CB: IEC 62368-1:2018
RCM: AS/NZS 62368.1:2022
CB: IEC 62368-1:2018
Security (common environments)
Standards: UL/CSA Safety: UL 62368-1 (3rd ed., rev. 13 Dec 2019), C22.2 No. 62368-1:19 (3rd ed., rev. 13 Dec 2019)
Garanti
2 års fabriksgaranti
