OTD140 - Outdoor router 4G

5G Sub-6GHz SA/NSA: up to 2.1/3.3 Gbps download (4x4 MIMO), 900/600 Mbps upload (2x2)
4G LTE Cat 20: up to 2.0 Gbps download / 200 Mbps upload
3G: up to 42 Mbps download / 5.76 Mbps upload
3GPP standard: Release 15/16 depending on hardware version
SIM switching: Dual SIM support with automatic switching in case of: weak signal, data limit, SMS limit, roaming, no network, network access denied, data connection failed or SIM idle.
Status information: IMSI, ICCID, operator, operator status, data connection status, network type, CA indicator, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, sent/received data, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC and MNC.
SMS features: SMS status, SMS configuration, send/read SMS via HTTP POST/GET, email to SMS, SMS to email, SMS to HTTP, SMS to SMS, scheduled SMS, auto-reply to SMS, SMPP support.
USSD: Support for sending and reading USSD (Unstructured Supplementary Service Data) messages.
Block/Allow List: Block and allow list for operators (based on country or individual operators).
Multiple PDNs (Public Data Networks): Ability to use different PDN connections for multiple network accesses and services.
Tape management: Tape locking and display of current tape usage.
SIM Sleep Protection Service: Ability to configure the router to periodically switch to the unused SIM card and establish a data connection to prevent the SIM card from being blocked.
Manage SIM PIN: SIM PIN management allows you to set, change, or disable the SIM card PIN.
Passthrough: The router assigns its mobile WAN IP address to another device on the LAN.
Forward Routing: Forward Routing: Support for an IP network behind 5G UE (User Equipment).

Wireless mode: 802.11b/g/n/ac Wave 2 (Wi-Fi 5) with transfer rates up to 867 Mbps (Dual Band, MU-MIMO), 802.11r fast handover, Access Point (AP), Station (STA).
Wi-Fi Security: WPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, automatic encryption modes, client separation, EAP-TLS with PKCS#12 certificate, disable auto-reconnect, 802.11w Protected Management Frames (PMF).
SSID/ESSID: ESSID invisible mode.
Wi-Fi users: Up to 150 simultaneous connections.
Wireless connectivity features: Wireless mesh (802.11s), fast roaming (802.11r), Relayd, BSS transition management (802.11v), radio resource metering (802.11k).
Wireless MAC filtering: Allow list, block list.
Wireless QR Code Generator: When scanned, a user will automatically connect to the network without having to enter login information.
TravelMate: Forward the Wi-Fi hotspot landing page to a subsequent connected device.

WAN: 1 x WAN port 10/100/1000 Mbps, compliant with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX cross-connect.

LAN: 4 x LAN ports, 10/100/1000 Mbps, compatible with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX cross-connect.

Routing: Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy-based routing.
Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN.
VoIP passthrough support: H.323 and SIP alg protocol NAT helper, enabling proper routing of VoIP packets.
Connection Monitoring: Ping Restart, Wget Restart, Periodic Restart, LCP and ICMP for link inspection.
Firewall: Port forwarding, traffic rules, custom rules, TTL target customization.
Firewall Status Page: View all firewall statistics, rules, and rule counters.
Port Management: View the device's ports, enable and disable each port, turn auto-configuration on or off, change the transmission speed, and more.
Network topology: Visual representation of your network, showing which devices are connected to which other devices.
Hotspot: Captive portal (hotspot), internal/external Radius server, Radius MAC authentication, SMS authorization, SSO authentication, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user restrictions or group restrictions, user management, 9 pre-selected customizable themes and the ability to upload and download custom hotspot themes.
DHCP: Static and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcards.
QoS / Smart Queue Management (SQM): Traffic prioritization via queues based on source/destination, service, protocol or port, WMM, 802.11e.
DDNS: Supports over 25 service providers, others can be configured manually.
DNS over HTTPS: DNS over HTTPS proxy enables secure DNS resolution by routing DNS requests over HTTPS.
Network backup: Wi-Fi WAN, cellular, VRRP, wired connections, each can be used as automatic failover.
Load Balancing: Balance of Internet traffic across multiple WAN connections.
SSHFS: Ability to mount a remote file system via SSH protocol.
VRF Support: Initial support for virtual routing and forwarding (VRF).
Traffic management: Real-time monitoring, wireless signal graphs, traffic history.

802.1x: Port-based network access control client.
Authentication: Distributed key, digital certificates, X.509 certificates, TACACS+, Internal and external RADIUS user authentication, IP and login attempt blocking, time-based login blocking, built-in random password generator.
Firewall: Pre-configured firewall rules that can be enabled via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T, NAT64.
Attack prevention: DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scanning prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scanning attacks).
VLAN: Port and tag-based VLAN separation.
Mobile quota control: Mobile data limit, customizable period, start time, warning limit, phone number.
WEB filter: Blacklist to block unwanted websites, Whitelist to specify only allowed pages.
Access Control: Flexible access control for SSH, web interface, CLI, and Telnet.
SSL certificate generation: Let's Encrypt and SCEP certificate generation methods.

OpenVPN: Multiple clients and one server can run simultaneously, 27 encryption methods.
OpenVPN Encryption: DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192,
BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128, AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128, AES-128-OFB 128, AES-128-GCM 128, AES-192-CFB 192, AES-192-CFB1 192, AES-192-CFB8 192, AES-192-OFB 192, AES-192-CBC 192, AES-192-GCM 192, AES-256-GCM 256, AES-256-CFB 256, AES-256-CFB1 256, AES-256-CFB8 256, AES-256-OFB 256, AES-256-CBC 256.
IPsec: XFRM, IKEv1, IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES192, AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12, AES256GCM12, AES128GCM16, AES192GCM16, AES256GCM16).
GRE: GRE tunnel, support for GRE tunnel over IPsec.
PPTP, L2TP: Client/Server instances can run simultaneously, support for L2TPv3, L2TP over IPsec.
Stunnel: Proxy designed to add TLS encryption functionality to existing clients and servers without making any changes to the application's code.
DMVPN: Method for building scalable IPsec VPNs, support for Phase 2 and Phase 3 and Dual Hub.
SSTP: Support for SSTP client instance.
ZeroTier: Support for ZeroTier VPN client.
WireGuard: Support for WireGuard VPN client and server.
Tinc: Tinc offers encryption, authentication, and compression in its tunnels. Client and server support.
Tailscale: Tailscale offers speed, stability, and simplicity over traditional VPNs. Encrypted point-to-point connections using the open source WireGuard protocol.

Supported modes: Client, Server
Supported connection types: TCP

Supported modes: Server, Client
Supported connection types: TCP, USB
Custom Registers: MODBUS TCP custom register block requests, which read/write to a file inside the router and can be used to extend MODBUS TCP Client functionality.
Supported data formats: 8-bit: INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII.

Protocols: HTTP(S), MQTT, Azure MQTT, Kinesis. Extract parameters from multiple sources and different protocols, and send them all to a single server. Custom LUA scripting, allowing scripts to use the router's Data to Server feature.

Enables sending commands and receiving data from a MODBUS server via an MQTT broker.

Supported modes: Station, Substation (Outstation)
Supported connections:TCP, USB

DLMS support: DLMS – standard protocol for data exchange from electricity meters and other meters.
Supported modes: Client
Supported connection types: TCP, USB
COSEM: Enables scanning of the meter's COSEM object for automatic detection and configuration.

Teltonika Networks Web API support (beta): Extend the capabilities of your device by using a number of configurable API endpoints to retrieve or modify data. For more information, see the documentation at: https://developers.teltonika-networks.com

WEB UI: HTTP/HTTPS support. View status, configure the device, update firmware, use command line (CLI), troubleshoot, multiple log servers, notifications about available firmware updates, event log, system log, kernel log, internet status.
FOTA: Firmware update from server, automatic update notifications.
SSH: Support for SSH (v1, v2)
SMS: SMS status and configuration. Send/read SMS via HTTP POST/GET.
Calls: Restart, show status, turn mobile data on/off, turn outputs on/off, answer/hang up with timer, turn Wi-Fi on/off.
TR-069: Support for OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem.
MQTT: Support for MQTT Broker and MQTT Publisher.
SNMP: Support for SNMP (v1, v2, v3), SNMP Trap, protection against bruteforce attacks.
JSON-RPC: Management API over HTTP/HTTPS.
RMS: Support for Teltonika Remote Management System (RMS).

ThingWorx: Enables monitoring of: WAN type, WAN IP, mobile operator name, mobile signal strength, mobile network type.
Enables monitoring of: Device model, version and serial number, WAN type and IP, mobile cell ID, ICCID, IMEI, connection type, operator, signal strength. Also supports remote actions such as reboot and firmware update.
Azure IoT Hub: Can be configured with the "Data to Server" feature to send all available parameters to the cloud. Supports "Direct method" which allows RutOS API commands to be executed directly from IoT Hub. Also offers Plug and Play integration with Device Provisioning Service for automatic, touchless device enrollment.
AWS IoT Core: Tools for interacting with the AWS cloud platform. Supports "Jobs" which allows you to call the device API via AWS Jobs functionality.

CPU: Quad-core ARM Cortex A7, 717 MHz
RAM: 256MB
FLASH storage: 256 MB

Web interface (WEB UI): Update firmware from file, check firmware on server, manage configuration profiles, backup configuration.
FOTA: Update firmware (over the internet).
RMS: Update firmware and configuration for multiple devices at once.
Keep settings: Update firmware without losing the current configuration.
Factory Reset: A full factory reset restores all system settings, including IP address, PIN, and user data to the manufacturer's default configuration.

Operating system: RutOS (Linux-based on OpenWrt)
Supported programming languages: Busybox shell, Lua, C, C++, and Python. Java is available via the Package Manager.
Development tools: SDK package with associated build environment provided.
GPL Customization: Create your own customized and branded firmware and web application by changing colors, logos, and other elements to suit your or your customers' needs.
Package Manager: The package manager is a service used to install additional software on your device.

GNSS: Support for GPS, GLONASS, BeiDou, Galileo and QZSS
Coordinates: GNSS coordinates available via WebUI, SMS, TAVL and RMS
NMEA: Support for the NMEA 0183 protocol
NTRIP: Support for the NTRIP protocol (Networked Transport of RTCM via Internet Protocol)
Server software: Supports server software such as TAVL and RMS
Geofencing: Ability to configure multiple geographic zones (geofences)

Data transfer speed: USB 2.0
Application: Samba sharing, USB-to-serial
External devices: Ability to connect external hard drives, flash drives, additional modems, printers, and USB-to-serial adapters
Storage formats: FAT, FAT32, exFAT, NTFS (read-only), ext2, ext3, ext4

Input: 1 x Digital input, 0 - 6 V detected as low logic, 8 - 30 V detected as high logic
Output: 1 x Digital output, Open collector output, max output 30 V, 300 mA
Events: Email, RMS, SMS
I/O juggler: Ability to set specific I/O conditions to initiate events.

Connection: 4-pin industrial DC power supply connector
Input voltage range: 9 – 50 VDC, reverse polarity protection, overvoltage protection >51 VDC 10us max
PoE (passive): Ability to supply power via the LAN1 port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 50 VDC
Power consumption: Sleep: < 4 W, Max: < 16.5 W

Ethernet: 5 x RJ45 ports, 10/100/1000 Mbps
I/O: 1 x Digital input, 1 x Digital output on 4-pin power supply connector
Status LED: 4 x WAN type, 3 x Mobile connection type, 3 x Mobile connection strength, 10 x Ethernet port status, 1 x Power, 2 x 2.4G and 5G Wi-Fi
SIM: 2 x SIM card slots (Mini SIM – 2FF), 1.8 V/3 V
Power: 1 x 4-pin power supply connector
Antenna: 4 x SMA for cellular, 2 x RP-SMA for Wi-Fi, 1 x SMA for GNSS
USB: 1 x USB A port for external devices
Reset: Restart/User default reset/Factory reset button
Other: 1 x Grounding screw

Housing material: Aluminum housing
Dimensions: (W x H x D): 132 x 44.2 x 95.1 mm
Weight: 533g
Mounting options: DIN rail, wall mount, flat surface (all require additional kit)

Operating temperature: -40°C to 75°C
Operating humidity: 10% to 90% non-condensing
Ingress protection: IP30

CE, UKCA, RCM, IMDA, CB, E-mark, SIRIM, ETSI EN 303 645, SDPPI (POSTEL)

EN 55032:2015 + A11:2021 + A1:2020
EN 55035:2017 + A11:2020
EN IEC 61000-3-2:2019 + A1:2021
EN 61000-3-3:2013 + A1:2019 + A2:2021
EN 301 489-1 V2.2.3, EN 301 489-3 V2.1.1, EN 301 489-17 V3.2.4, EN 301 489-19 V2.2.1, EN 301 489-52 V1.2.1
ESD: EN 61000-4-2:2009
Radiated Immunity: EN IEC 61000-4-3:2020 / EFT: EN 61000-4-4:2012
Surge Immunity (AC Mains Power Port)
EN 61000-4-5:2014 + A1:2017
CS: EN 61000-4-6:2014
DIP: EN IEC 61000-4-11:2020
RF Standards: EN 300 328 V2.2.2, EN 300 440 V2.2.1, EN 301 893 V2.1.1, EN 301 908-1 V13.1.1, EN 301 908-2 V13.1.1, EN 301 908-13 V13.1.1, EN 301 908-25 V15.1.1_15.0.6, EN 303 413 V1.2.1

2 års fabriksgaranti
